A roof design gives the chance to extra floor space in the roof volume similar to a space or upper room space.

Lamella roof ppt.

See more ideas about roof roof design architecture. Lamella roof vaulted roof consisting of a crisscrossing pattern of parallel arches skewed with respect to the sides of the covered space composed of relatively short members lamellae hinged together to form an interlocking network in a diamond pattern. Hip a hip roof is a gable roof with angled ends taking the place of the gable end of the structure. The individual pieces are joined together with bolts and or plates to form a rhomboid pattern.

Once the curve of the roof was defined in a 3d model we were able to take information and translate it to full scale templates that guided our tools in the fabrication of the pieces. It can likewise loan itself pleasantly to dormers which expands the usable floor zone and characteristic light. A new lightweight polycarbonate lamella roof concept from bayer material science combines transparency sealing opening and closing functions. May 19 2019 explore greg camacho s board lamella roofs on pinterest.

Sep 4 2017 explore randal pope s board lamella roofs on pinterest. A lamella roof also known as the zollinger roof after friedrich zollinger is a vaulted roof made up of simple single prefabricated standard segments mostly in timber as a way to span large spaces. We then used an aseembly line for the manufacturing of the different parts for each piece. The individual pieces are joined together with bolts and or plates to form a rhomboid pattern.

Because of its simplicity and markable rigidity it was soon used for many large roofs worldwide which could span up to 40 m. A gable roof consists of two shed roof structures joined at the peak forming a ridge line. See more ideas about roof architecture timber structure. In 1924 and 1925 hugo junkers 1859 1935 patented a steel lamella roof construction based on the wood lamella roof design by fritz zollinger.
